Monoblock bridge saw with 5 interpolating axes. Strong and robust frame structured in steel. Hot-dip galvanized bench (tilting table available as an option). Widely used and suitable for cutting any kind of natural stone, synthetic stone, porcelain stoneware, and ceramic. An intuitive and easy-to-use interface “Touch and Go” with 20 automatic functions facilitates daily use of the machine. Frame and rail with ceramic-based paint resistant to corrosion over time.
Technical Data | |||||||||
ITEM | MOD. | ||||||||
160600 | FRESA MANTA POKER 3500 TOP | 450 | 600 – 6000 | 15 – 400 | 2100×3500 | 250 | 140 – Ø 450 | 583x230x251 | 3200 |
STANDARD EQUIPMENT:
- Blade speed inverter
- Hanging CNC panel with a 15” touchscreen interface
- Spindle with 1/2 gas connection for core bits and cutters
- Adjustable feet
- Slab stops
- Electrically powered line laser (green)
- Disc diameter measuring device
- Automatic lubrication
OPTIONAL:
- Diamond blade
- Tilting table
- Wide range of worktops
- Table with built-in omni rollers
- LED light for the work area lighting
- Water tray in PVC complete with pump
- Slab thickness detector
- Remote control keypad
- CAM software, CAD-CAM software
- PC with floor stand
- Slab detecting camera
- On-site installation and training for operators
